Schüco AWS 70.BS.HI

High insulation thermal break window system, with total face width of 71mm.
The extended thermal insulation zone with the specially designed thermal break chambers with foam ensure top energy-saving performance and minimise heat loss. This system’s energy profiles is complemented by top sealing performance, featuring high wind pressure resistance, air and water permeability.

TECHNICAL CHARACTERISTICS

Dimensions:

Frame profile depth: 70 mm

Frame face width: 66,5 mm

Maximum glass thickness: 17-41 mm casement 21-39 mm sheet mm

Sheet profile depth: 80 mm

Sheet face width: 50mm

Mechanism: SCHÜCO Simply Smart mechanism and basic security category

Extended thermal insulation zone with thermal breaks and chambers with foam

EPDM sealing gaskets

Profiles have straight form

Coplanar casement and sheet

Charge groups in accordance with DIN EN 12207/12208/12210

Thermal Insulation: Uf  1.6 W/m2K in accordance with DIN EN ISO 10077-2

Soundproofing up to Rw=45dB in accordance with DIN EN ISO 140-3

Burglar resistance up to RC3 in accordance with DIN V ENV 1627

Air permeability in accordance with DIN EN 12207 Class: 4

Water permeability in accordance with DIN EN 12208 Class: 9a

Wind pressure resistance in accordance with DIN EN 12210: Class:C5 / B5

Mechanical strength in accordance with DIN EN 13115 Class: 4

Functionality over time in accordance with DIN EN 12400 Class: 3
